Beskrivning
43-AM4917MZT4 Dino-Lite Mikroskop > Extra hög förstoring större än 220x > Med polarisator
- EDOF (Extra stort skärpedjup)
- EDR (Extra stort exponeringsomfång)
- AMR (Automatisk förstoringsavläsning)
- eFLC (Utökad flexibel ljuskontroll)
- DPQ (djupmätning)
As magnification increases, targets with uneven surfaces are often out of focus due to the limited depth of field. The AM4917MZT4 400x digital microscope eases focusing with its click-to-focus functionality and can generate focused-stacked images with EDOF. Delivering superior images, equipped with a polarizer, and featuring EDOF, DPQ, AMR, and EDR, the AM4917MZT4 is a quality imaging tool ready for a wide range of applications.
Note: EDOF, EDR, and DPQ are available on Windows PC only.
The main features of the AM4917MT8 are:
• 1.3 Megapixels
• Extended Depth of Field (EDOF)
• Extended Dynamic Range (EDR)
• Automatic Magnification Reading (AMR)
• Extended Depth of Field (EDOF)
• Enhanced Flexible LED Control (eFLC)
• Integrated polarizer (anti-reflection)
• 400x-470x magnification
• And more…
(*EDOF/EDR only functions under Windows OS)
| MAGNIFICATION RATE | WORKING DISTANCE * | FIELD OF VIEW(X) | FIELD OF VIEW(Y) | DEPTH OF FIELD |
400 | 5.68 | 0.977 | 0.732 | 0.041 |
410 | 6.63 | 0.953 | 0.715 | 0.040 |
420 | 7.59 | 0.93 | 0.698 | 0.039 |
430 | 8.55 | 0.909 | 0.681 | 0.038 |
440 | 9.51 | 0.888 | 0.666 | 0.038 |
450 | 9.62 | 0.868 | 0.651 | 0.037 |
460 | 9.56 | 0.849 | 0.637 | 0.036 |
470 | 9.50 | 0.831 | 0.623 | 0.036 |
| Listed values may differ slightly | * Without front cap | Unit = mm | ||
| Lighting | |
|---|---|
| Light/ LED type | White |
| Number of LEDs | 8 |
| Optics | |
| Magnification | 400x ~ 470x |
| Sensor | |
| Sensor type | CMOS |
| Resolution | 1.3 Megapixels (1280 x 960) |
| Maximum frame rate | 30 fps in 1.3 MP, MJPEG 30 fps in VGA, MJPEG |
| Compatibility | |
| Interface | USB 2.0 |
| Operating system | Windows 7, 8, 10 & 11, MacOS 10.12 and up |
| Included software | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
| Supported image formats (Windows) | BMP, GIF, PNG, MNG, TIF, TGA, PCX, WBMP, JP2, JPC, JPG, PGX, RAS, PNM |
| Supported video formats (Windows) | WMV, FLV, SWF |
| Supported image formats (MacOS) | PNG, JPEG |
| Supported video formats (MacOS) | MOV |
| Housing | |
| Housing material | Metal housing |
| Dimensions | 10.7 cm (H) x 3.3 cm (D) |
| Weight | 130 g |
| Features | |
| Measurement | Yes |
| Calibration | Yes |
| Microtouch sensor | Yes |
| Information | |
| Warranty information | 2 years European warranty |
| Regulatory approval | CE, FCC, ROHS, UKCA – available upon request – marketing@dino-lite.eu |
